NC-1325-ATC CNC Router
Product Introduction
Adopt constant power air cooling ATC spindle, high speed, low noise and long life. X, Y axes are using gear and rack transmission and Z axis is with precision ball screw vice transmission, reasonable structure, stable performance, good weight bearing ability.
This machine is a heavy duty CNC router machine, equipped with auto tool changing system, high performance, especially suitable for advertisement and wood furniture industrial processing.
This series utilizes an industry standard G-code for control functions that allows easy interfacing with all major CAD/CAM software and industry standard solid modeling software packages.
Main Features
- Industrial steel pipe frame with strong legs, with stable moving, low noise and high precision.
- WEIHONG NK260 control cabinet system
- Stable air cooling ATC spindle motor 9kw
- Cast steel gantry stand
- 8 Position linear ATC Station
- High precision and durable guide rail imported from Taiwan
- Linear Square Guide: 20MM linear square guide with double bearings, an ultra-heavy type that achieves a deep grooved raceway with its diameter more approximate to the ball diameter and has high rigidity, vibration and shock resistance, and damping characteristics, which are required for machine tools
- Equipped with Taiwan Gear Speed reducer device, which makes the corner cutting and engraving with smoother edges.
- Servo motor and drivers & planetary gearbox
- Double bags of dust collector
Technical Parameters
| Model | NC-1325ATC |
| Table Size | 1368x3120mm |
| Working Size | 1300x2500x250mm |
| Max. Material Height | 180mm |
| Spindle Power | Chinese 9KW ATC Spindle Motor |
| Psi/Cfm | 90/16 |
| Tool Holder | ISO 30,ER32 |
| ATC Tool Station | Linear 8 position |
| Speed RPM | 0-24000rpm |
| Motor and Driver | Leadshine Servo motors and drivers |
| CNC | WEIHONG NK260 |
| Tool Diameter | Ø3.175,Ø4,Ø6,Ø12.7 |
| Mechanical Structure | Square Steel Pipe |
| Transmission | Ball Screw for Z ; Helical Gearbox and Rack & Pinion for X,Y |
| Guide Rails | Imported Linear Guide Rails |
| Repositioning Accuracy | <0.03mm/300mm |
| MAX. Engraving Speed | 45000mm/min |
| Table Top | PVC Vacuum Table |
| Vacuum Pump | Air cooling 7.5kw |
| File Transfer | USB or Net-work |
| File Format | G Code or HPGL |
| Power Supply | 380V,50-60Hz |
| External Form Size | 2100x3460x1950mm |
| Packing Size | 2250x3610x2100mm |
| Net/Gross Weight | 550/800kg |
| Optional Models | NC-1313ATC， NC-1318ATC，NC-1530ATC, NC-2040ATC |
Available materials
Wood, MDF, organic glass, acrylic, plastic material, marble, Aluminum Composite Sheet, Aluminum etc..
Application
Professionally used in advertising industry, model industry, toy, art gift, advertisement decoration, building upholster, package printing, wood product, furniture industry and other industries.
Samples
